2020LCDpanelandhinges
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1030Smallbottomcover”onpage64
•“1040Opticaldriveorblankbezel”onpage65
•“1070PCIExpressMiniCardforwirelessLAN”onpage68
•“1080PCIExpressMiniCardforwirelessWANormSATAsolidstatedrive”onpage69
•“1120Keyboard”onpage76
•“1130Keyboardbezel”onpage80
•“1190RJ45subcard”onpage91
•“1210LCDunit”onpage94
•“2010LCDbezelassembly”onpage99
RemovalstepsofLCDpanelandhinges
StepScrew(quantity)Color
Torque
1
M2.5×4mm,wafer-head,nylon-coated(4)
Black0.294Nm
(3kgf-cm)
Chapter9.RemovingorreplacingaFRU101
