1100Thermalfan
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
Removalstepsofthermalfan
Note:Loosenthescrews2.
Note:Yourmodelmightlookslightlydifferentfromtheillustrationabove.
Wheninstalling:Makesurethattheconnectorisattachedrmlytothesystemboard.
Note:Yourmodelmightlookslightlydifferentfromtheillustrationabove.
Wheninstalling:Donotpressthetopofthefancoverandthefanhub.
1110Thermalpipes
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
