Lenovo ThinkPad Edge E535 Hardware Maintenance Manual

Frontview
Forsomemodels:
1
2
2
9
11
10
12
13
14
15
3
4
5
6
7
8
1Integratedcamera9Mediacardreaderslot
2Built-inmicrophones
10Fingerprintreader(onsomemodels)
3acpowerconnector
11Touchpad
4RJ45Ethernetconnector12TrackPointbuttons
5Opticaldriveorblankbezel
13TrackPointpointingstick
6AlwaysOnUSBconnector
14UltraNav
®
pointingdevice
7Comboaudiojack
15Powerbutton
8Systemstatusindicator
1
1
:Forthedescriptionofthesystemstatusindicator,seeChapter5“Statusindicators”onpage43.
48HardwareMaintenanceManual
