Note:Yourmodelmightlookslightlydifferentfromtheillustrationabove.
Wheninstalling:
Note:Ifonlyonememorymoduleistobeinstalledonthecomputeryouareservicing,thememorymodule
mustbeinstalledinSLOT-0(alowerslot),butnotinSLOT-1(bupperslot).
Insertthenotchedendofthememorymoduleintotheslot.Pressthememorymodulermly,andpivotit
untilitsnapsintoplace.Makesurethatitisrmlyinstalledintheslotanddoesnotmoveeasily.
1060Harddiskdriveassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
Attention:
•Donotdropthedriveorapplyanyphysicalshocktoit.Thedriveissensitivetophysicalshock.Improper
handlingcancausedamageandpermanentlossofdata.
•Beforeremovingthedrive,havetheusermakeabackupcopyofalltheinformationonitifpossible.
•Neverremovethedrivewhilethecomputerisoperatingorisinsuspendmode.
66HardwareMaintenanceManual
