1090
Backup
battery
F
or
access,
remove
these
FRUs
in
or
der:
•
“1010
Battery
pack”
on
page
62
•
“1030
Small
bottom
cover”
on
page
64
Removal
steps
of
backup
battery
DANGER
Use
only
the
authorized
battery
specied
for
your
computer
.
Any
other
battery
could
ignite
or
explode.
When
installing:
Make
sur
e
that
the
connector
is
attached
rmly
.
Chapter
9
.
Removing
or
replacing
a
FRU
73
78
80
