•“1020Largebottomcover”onpage63
•“1030Smallbottomcover”onpage64
•“1040Opticaldriveorblankbezel”onpage65
•“1050Memorymodules”onpage65
•“1060Harddiskdriveassembly”onpage66
•“1070PCIExpressMiniCardforwirelessLAN”onpage68
•“1080PCIExpressMiniCardforwirelessWANormSATAsolidstatedrive”onpage69
•“1090Backupbattery”onpage73
•“1100Thermalfan”onpage74
•“1110Thermalpipes”onpage74
•“1120Keyboard”onpage76
•“1130Keyboardbezel”onpage80
•“1140CPU”onpage82
Removalstepsofsystemboard
Attention:Thefollowingcomponentssolderedonthetopsideofthesystemboardareextremelysensitive.
Whenyouservicethesystemboard,avoidanykindofroughhandling.
aCPU
bPlatformControllerHub(PCH)
cGraphicsProcessingUnit(GPU)(discretegraphicscard)
Formodelswithadiscretethermalmodule
