When installing:
1. Place the keyboard bezel so that the three latches are
fixed in place 1.
1
While inserting the three latches, align the top-left
corner of the keyboard bezel as in figure a.
a
(continued)
2. Press the left edges 2 and the front edges 3 of the
keyboard bezel until the latches are snapped.
Removing and replacing a FRU
94 R50e, R51e and R52 Series
