6.InsertonesideoftheTR300KeyunderoneoftheretainingclipsontheiButtonsocket.Then,carefully
presstheothersideoftheTR300Keystraightdownuntilthekeysnapsintopositionandissecured
bythetworetainingclipsontheiButtonsocket.
Figure58.InstallingtheTR300Key
7.Ifyouhaveliftedtherisercardassembly1,reinstallitintothechassis.See“Replacingtherisercard
assembly1”onpage160
.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage170.Then,theonboard
SASsoftwareRAID5isavailableforyourserverifyourserverhastherequirednumberofharddiskdrives
installed.ToconfigureRAID,see“ConfiguringRAID”onpage62
.
RemovingtheTR300Key
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage73.
102ThinkServerRD340UserGuideandHardwareMaintenanceManual
