8.Touchthestatic-protectivepackagethatcontainsthenewmicroprocessortoanyunpaintedsurfaceon
theoutsideoftheserver.Then,removethenewmicroprocessorfromthepackage.
9.Removetheprotectivecoverthatprotectsthegoldcontactsonthebottomofthenewmicroprocessor.
Donottouchthepinsonthemicroprocessorsocketandthegoldcontactsonthebottomofthenew
microprocessor.
Figure76.Donottouchthepins
10.Notetheorientationofthenewmicroprocessor.Holdthenewmicroprocessorbyitsedgesandalign
thenotches
1onitwiththetabs2inthemicroprocessorsocket.Then,carefullylowerthenew
microprocessorstraightdownintothemicroprocessorsocket.
Note:Thesmalltriangle3ononecornerofthenewmicroprocessoristhemicroprocessororientation
indicator.Thenewmicroprocessorisinthecorrectorientationwhenthisindicatorfacesthebeveled
corner
4ofthemicroprocessorsocket.
Figure77.Installingthemicroprocessor
126ThinkServerRD340UserGuideandHardwareMaintenanceManual
