Lenovo ThinkServer RD340 - System Board Components and Layout; Configuring the Server; Using the Setup Utility Program

Figure29.Systemboardcomponents
1Frontpanelconnector17Risercardassembly1slot
2InternalUSBconnector1
18Risercardassembly2slot
3InternalUSBconnector2
19Redundantpowersupplyconnector1
4IntelligentDiagnosticsModuleconnector20Redundantpowersupplyconnector2
5FrontVGAconnector
21Backplanepowerconnector1
6SATAconnector0
22Backplanepowerconnector2
7SASconnector4-723Systemfan7connector
8SASconnector0-3
24Microprocessorsocket2
9Coin-cellbattery25Systemfan6connector
10PlatformControllerHub(PCH)26Memoryslots(6)
11InternalUSBTypeAconnector127Systemfan5connector
12TMMPremiumconnector
28Systemfan3connector
13InternalUSBTypeAconnector2
29Microprocessorsocket1
14TPMconnector
30Systemfan2connector
15iButtonsocket
31Memoryslots(6)
16ThinkServerManagementModule32Systemfan1connector
Chapter3.Productoverview39
