•IfyouareusingaThinkServerRAID700Adapter,dothefollowing:
1.Useonemini-SAStomini-SASsignalcable.Connectthemini-SASconnector3ononeendofthe
cabletotheports3-0ontheRAIDcard.Then,connectthemini-SASconnector4ontheotherend
ofthecabletothemini-SASports0-3onthebackplane.
2.Ifyourserverhasmorethanfourharddiskdrivesinstalled,usetheothermini-SAStomini-SASsignal
cable.Connectthemini-SASconnector1ononeendofthecabletotheports7-4ontheRAID
card.Then,connectthemini-SASconnector2ontheotherendofthecabletothemini-SASports
4-5ormini-SASprots4-7onthebackplane.
•IfyouareusingaThinkServerRAID710Adapter,dothefollowing:
1.Usethemini-SAStomini-SASsignalcable.Connectthemini-SASconnector1totheport1onthe
RAIDcard.Then,connectthemini-SASconnector2tothemini-SASports0-3onthebackplane.
2.Ifyourserverhasmorethanfourharddiskdrivesinstalled,usetheothermini-SAStomini-SAS
signalcable.Connectthemini-SASconnector
3totheport2ontheRAIDcard.Then,connectthe
mini-SASconnector4tothemini-SASports4-5ormini-SASports4-7onthebackplane.
Refertothefollowingtopicsforinformationabouttheconnectorlocations:
•“Hot-swaphard-disk-drivebackplane”onpage33
•“RAIDcard”onpage31
•“Systemboardcomponents”onpage38
Systemboardcomponents
Thefollowingillustrationshowsthecomponentlocationsonthesystemboard.
