Frontviewofservermodelswithaninternaltapedrive
0
1
2
3
4
5
6
7
Figure8.Frontviewofservermodelswithaninternaltapedrive
1Rackhandle(left)
2Frontpanel
3Pull-outinformationcard
4Internaltapedrive(availableonsomemodels)
5Slimopticaldrive(availableonsomemodels)6Rackhandle(right)
72.5-inch-drivebays(0–7)
16Rackhandles
Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestohelpyouslidetheserveroutof
therackcabinet.Youalsocanusetherackhandlesandscrewstosecuretheserverintherackcabinetso
thattheservercannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRack
InstallationInstructionsthatcomeswithyourserver.
2Frontpanel
Forinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Frontpanel”
onpage25.
3Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage18.
4Internaltapedrive
Someservermodelscomewithaninternaltapedrive.Theinternaltapedriveenablesyoutostoredataon
tapes.
5Slimopticaldrive
SomeservermodelscomewithaslimSATAopticaldrive(DVD-RWorDVD-ROM).
72.5-inch-drivebays(0–7)
TheEMIintegrityandcoolingoftheserverareprotectedbyhavingalldrivebayscoveredoroccupied.
Thenumberoftheinstalleddrivesinyourservervariesbymodel.Thevacantdrivebaysareoccupied
bydummytrays.
Whenyouinstalldrives,followtheorderofthedrivebaynumbers.
