1 2 3 4 5
6
7
8 9 10
11
12
13
14
15
16
17
18
23
34
19
21
20
22
24
25
26
27
28
29
30
31
32
33
35
Figure37.Systemboardcomponents
1SATAconnector1(ports4-7)
2AnyRAIDconnector0-1
3SATAconnector0(ports0-3)
4Frontpanelconnector2
5Frontpanelconnector1
6Coin-cellbattery
7SATAconnector(opticaldrive)
8AnyFabricconnector
9RAIDupgradekeyconnector
10SDmoduleconnector
11Risercardassembly1slot
12PCIeslot4
13TPMconnector
14TSMconnector
15Rear-backplanesignalconnector16Risercardassembly2slot
17PCIeslot718PCIeslot8
19Rear-backplanepowerconnector20Front-backplanepowerconnector
21Intrusionswitchconnector
22Serial-port-moduleconnector
23Power-distribution-boardconnector
24Systemfan6connector
25Microprocessor2memoryslots(6)26Systemfan5connector
27Microprocessor2socket
28Systemfan4connector
29Microprocessor2memoryslots(6)30Systemfan3connector
31Microprocessor1memoryslots(6)32Systemfan2connector
33Microprocessor1socket
34Systemfan1connector
35Microprocessor1memoryslots(6)
1SATAconnector1(ports4-7)
UsedtoconnecttotheSATA4–7connectorontheLenovoThinkServerRAID110iAnyRAIDAdapter.
3SATAconnector0(ports0-3)
UsedtoconnecttotheSATA0–3connectorontheLenovoThinkServerRAID110iAnyRAIDAdapter.
Chapter3.Productoverview49
