Chapter 3. 3-1
Chapter 3. Reference information
3
This section contains monitor specifications, instructions to manually install the monitor driver,
troubleshooting information, and service information.
Monitor specifications
Table 3-1. Monitor specifications for type-model 63ED-MAR2-WW
Dimensions Depth 178.6 mm (7.03 inch)
Height 497.2 mm (19.57 inch)
Width 539.4 mm (21.24 inch)
Stand Lift
Tilt
Swivel
Pivot
155 mm
-5° to 22°
-360° to 360°
-90° to 90°
Weight Weight with stand assembly
4.7 kg (10.4 lbs)
Weight without stand
assembly (For wall mount or
VESA mount considerations
- no cables)
3.1 kg (6.9 lbs)
VESA mount Supported 100 mm x 100 mm (3.94 in. x 3.94 in.)
Image Viewable image size 604.7 mm (23.8 inch)
Maximum height 296.5 mm (11.67 inch)
Maximum width 527.0 mm (20.75 inch)
Pixel pitch 0.2745 mm (0.011 inch)
Power input Supply voltage 100-240V AC
50-60Hz
Max supply current 1.3A
Power consumption Normal operation <29.0 W (max)
<12.0 W (typical)
Note: Power
consumption figures
are for the monitor
and the power supply
combined
Standby/Suspend <0.5 W
Off <0.3 W
Video input (Analog) Interface
Input signal
VGA
Analog Direct Drive, 75 ohm 0.7V
Horizontal addressability 1920 pixels (max)
Vertical addressability 1080 lines (max)
Clock frequency 170 MHz
