CMVPFB01A 18
Cyclic Data Access - Dout Mapping
5.4.4 P44x = 3, Lenze C135 Control Word
The Lenze C135 Control Word consists of 16 control bits some of which are reserved.
Table 13: Lenze C135 Control Word
b15 b14 b13 b12 b11 b10 b9 b8
Network
Reference
Enable
DC
Braking
Reserved Reserved Fault
Reset
Reserved Controller
Inhibit
Network
Control
Enable
b7 b6 b5 b4 b3 b2 b1 b0
Reserved Reserved Reserved Reserved Quick
Stop
Direction
of Rotation
Network Setpoint Reference
Table 14: Lenze C135 Control Word BIT Functions
BIT Function Description
0 Network
Setpoint
Reference
Source
0 = Network
1 = Preset #1
2 = Preset #2
3 = Preset #3
(Active only when
Network Reference
is Enabled)
1
2 Direction of Rotation 0 = CW (FORWARD)
1 = CCW (REVERSE)
3 Quick Stop Set to 1 to disable the drive and stop the ramp time defined in P127
4 Reserved
5 Reserved
6 Reserved
7 Reserved
8
Network Control Enable
0 = Local Control
1 = Network Control
9 Controller Inhibit Set to 1 to disable the drive and allow the motor to coast to a stop
10 Reserved
11
Fault Reset
A 0-to-1 transition will reset the drive from a trip condition.
If the reason for the trip is still present or another fault condition has been detected, the
drive will immediately trip again. When resetting the drive, it is recommended to check
the status word to ensure that the reset was successful, before attempting to restart the
drive.
12 Reserved
13 Reserved
14 DC Braking Set to 1 to activate DC injection braking. Refer tp P174 & 175 for details.
15 Network Reference Enable 0 = Local Speed Reference
1 = Network Speed Reference
