Cyclic Data Access - Din Mapping
5.4.12 P46x = 3, Lenze C150 Status Word
The Lenze C150 Status Word consists of 16 control bits some of which are reserved.
Table 18: Lenze C150 Status Word
b15 b14 b13 b12 b11 b10 b9 b8
Drive
Healthy
Direction
of Rotation
Over
Voltage
Over Temp
Warning
Controller Status
b7 b6 b5 b4 b3 b2 b1 b0
Controller
Inhibit
At
Zero Speed
Above
Speed
At Setpoint
Speed
Reserved Current Limit
Status
Pulse
Inhibit
Reserved
Table 19: Lenze C150 Status Word BIT Functions
BIT Function Description
0 Reserved
1 Pulse Inhibit 0 = Pulse outputs enabled
1 = Pulse outputs inhibited
2 Current Limit Status 0 = Current limit not reached
1 = Current limit reached
3 Reserved
4 At Setpoint Speed 0 = Actual output frequency <> Setpoint value
1 = Actual output frequency = Setpoint value
5 Above Speed 0 = Actual output frequency <= P136 value
1 = Actual output frequency > P136 value
6 At Zero Speed 0 = Actual output frequency <> 0 Hz
1 = Actual output frequency = 0 Hz
7 Controller Inhibit 0 = Controller Enabled
1 = Controller Inhibited
8
Controller
Status
0 = No Fault
8 = Fault Present
9
10
11
12 Over Temp Warning 0 = No over-temperature fault
1 = Over-temperature fault
13 Over Voltage 0 = No DC bus over-voltage
1 = DC bus over-voltage
14 Direction of Rotation 0 = CW (FORWARD)
1 = CCW (REVERSE)
15 Drive Ready 0 = Not ready
1 = Ready (No Faults)
5.4.13 P46x = 4, Actual Speed in RPMs
Unsigned Actual Speed in RPMs. Range: 0 - 65535.
