Lenze AC Tech SMVector PROFIBUS-DP User Manual

CMVPFB01A 26
Cyclic Data Access - Din Mapping
5.4.17 P46x = 8, Digital I/O Status
The Digital I/O Status Word consists of 16 control bits some of which are reserved.
Table 24: Digital I/O Status Word
b15 b14 b13 b12 b11 b10 b9 b8
Reserved Reserved Reserved Reserved Reserved Relay
Active
TB14
Output Active
TB13C
Input Active
b7 b6 b5 b4 b3 b2 b1 b0
TB13B
Input Active
TB13A
Input Active
Reserved TB1
Active
Reserved Reserved Reserved Reserved
5.4.18 P46x = 9, Analog 0-10V Input
Analog Input: 0 - 10V in 0.1 VDC increments
Received Value = 0x3A = 5.8 VDC
5.4.19 P46x = 10, Analog 4-20mA Input
Analog Input: 4 - 20mA in 0.1 mA increments
Received Value = 0xA5 = 16.5 mA
5.4.20 P46x = 11, Actual PID Setpoint
Signed value: -999 to 31000
5.4.21 P46x = 12, Actual PID Feedback
Signed value: -999 to 31000
