41 CMVPFB01A
Parameter Reference
9. Parameter Quick Reference
Table 41 lists each parameter number and provides its function, default value and access rights.
Table 41: Parameter Quick Reference
Parameter Function Default Value Access Rights Cross Reference
P400 Network Protocol 0 RW
4.3: Configuring the SMV PROFIBUS-DP Module
P401 Module Revision 6.x.x RO
7.1: Option Module Advanced Parameters
P402 Module Status - RO
P403 Restore Defaults 0 RW
P404 Module Time-out Action 3 RW
P405 Network Fault - RO
7.2: Network Fault
P406 Reserved RO
P410 Node Address 126 RW
4.3.3: Node Address
P411 Network Baud Rate - RO
4.3.4: Baud /Data Rate
P413 Node Address Lock - RW
7.5: Node Address Lock
P415 Dout Data Size - RO
5.3: Channel Data Size
P416 Din Data Size - RO
P418 Re-Initialise - RW
4.3.6: Re-initialising
P419 Node Status - RO
4.3.7: Check Node Status
P420 Reserved - RO Factory Reference
P421 Sync and Freeze Status - RO
7.6: Sync and Freeze
P423 Master Monitoring Time-out - RO
7.3: Master Monitor
P424 Master Monitoring Time-out Action 4 RW
P425 Data Exchange Monitoring Time out - RO
7.4: Data Exchange
P426 Data Exchange Monitoring Time out Action 4 RW
P428 Data Exchange Frequency - RO
P429 Data Exchange Counter - RO
P430 Reserved -
P431 Acyclic Parameter Access Mode 0 RW
6.2.1: Acyclic Modes
P440 Dout Channel 0 mapping 1 RW
5.2.1: Data OUT Channels
P441 Dout Channel 1 mapping 2 RW
P442 Dout Channel 2 mapping 0 RW
P443 Dout Channel 3 mapping 0 RW
P444 Dout Channel 4 mapping 0 RW
P445 Dout Channel 5 mapping 0 RW
P449 Total Dout Data Size (in Bytes) - RO
7.7: Data Sizes
P450 Dout Data Monitor Select 0 RW
7.8: Debug Data Viewer
P451 Dout Data Monitor Value 0 RO
