Lenze AC Tech SMVector PROFIBUS-DP User Manual

CMVPFB01A 38
Advanced Features
7.6.2 Sync and Freeze Status
P421 - Sync and Freeze Status
Default: N/A Range: 0 - 7
Access: RO Type: Bit
Table 38: Sync and Freeze Status
P421 Value Description
Bit 0 Reserved
Bit 1 Clear Out Data
Bit 2 Unfreeze
Bit 3 Freeze
Bit 4 Unsync
Bit 5 Sync
Bit 6 Reserved
Bit 7 Reserved
7.7 Data Sizes
7.7.1 Dout Data Size
P449 - Dout Data Size (in Bytes)
Default: N/A Range: 0 - 20
Access: RO Type: Integer
This parameter displays in bytes the total amount of Dout data including outward going 4WPA data.
7.7.2 Din Data Size
P469 - Din Data Size (in Bytes)
Default: N/A Range: 0 - 20
Access: RO Type: Integer
This parameter displays in bytes the total amount of Din data including incoming 4WPA data.
7.8 Debug Data Viewer
The Debug Data Viewer parameters enable the viewing of raw data being passed between the network
master and the option module.
7.8.1 Dout Data Monitor Select
P450 - Dout Data Monitor Select
Default: 0 Range: 0 - 255
Access: R/W Type: Integer
This parameter selects which Dout word (including 4WPA) of data will be monitored.
