Cyclic Data Access - Din Mapping
5.4.15 P46x = 6, Drive RUN Status
The Drive RUN status indicates the run status the drive is currently in.
Table 22: Drive RUN Status
RUN Status Value Description
0 Drive Faulted, attempted restart & locked; Requires manual reset
1 Drive Faulted; Check P500 Fault History and correct fault condition
2 Drive has tripped into a fault and will automatically restart
3 Identification not complete
4 Forced Coast Stop
5 Drive is Stopped
6 Drive is Preparing to Run
7 Drive is in Identification State
8 Drive is in Run State
9 Drive is Accelerating
10 Drive is Decelerating
11 Drive stopped decelerating to avoid tripping HF fault, due to excessive motor regen (2 s max)
12 DC Injection brake activated
13 Flying Restart Attempt after Fault
14 Current Limit Reached
15 Fast Current Limit Overload
16 Drive is in Sleep Mode
5.4.16 P46x = 7, Drive Fault Status
The Drive Fault Status indicates the drive’s present fault condition.
Table 23: Drive Fault Status
Fault Codes
Fault
Number
Drive
Display
Fault Description
0 NO FAULT
1 F.AF Temperature Output Fault
2 F.OF Over Current Fault
3 F.OF1 Ground (Short to Earth) Fault
4 F.AF Excess Drive Temperature Fault
5 F.rF Fly Start Fault
6 F.hF High Bus Voltage (Over Voltage) Fault
7 F.LF Low Bus Voltage (Under Voltage) Fault
8 F.PF Motor Overload Fault
9 F.JF OEM Defaults Corrupted Fault
10 F.IL Illegal Setup Fault
11 F.dbF Dynamic Brake Overheated Fault
12 F.SF Single Phase Voltage Ripple to High Fault
