Mechanical installation
Arrangement of the devices
4

41
EDK94ZPP0364 ZH/EN 2.0
4.2 Arrangement of the devices
Power supply module
L1
L2
L3
M
3~
M
3~
M
3~
M
3~
E94AZxPxxxx
E94AZxPxxxx
E94APNExxxx
E94AZEX100
E94AZPxxxxx
E94AZPxxxxx
E94AZPxxxxx
E94AZPxxxxx
...
...
+UG
-UG
+UG
-UG
+UG
-UG
01
+
(E94AZPPxxxx)
SSP94FF003
Fig. 4-2 Arrangement concept
 Standard mounting: side mounting
 Mounting variant: top mounting
E94AZxPxxxx Filter
E94APNExxxx 9400 DC power supply module
(up to 36 A/18 kW with E94AZPPxxxx installation backplane)
E94AZEX100 DC input module
E94AZPxxxxx Installation backplane for 9400 axis module
