Lenze AC Tech PositionServo 941 - Specifications; Electrical Characteristics

S94P01C -e1
8
2 Specications
2.1 Electrical Characteristics
Single-Phase Models
Type
(1)
Mains Voltage
(2)
1~ Mains
Current
(doubler)
1~ Mains
Current
(Std.)
Rated Output
Current
(5)
Peak Output
Current
(6)
E94_020S1N_X
120V
(3)
or 240V
(4)
9.7 5.0 2.0 6
E94_040S1N_X 16.8 8.6 4.0 12
E94_020S2F_X
120 / 240V
(4)
(80 V -0%...264 V +0%)
-- 5.0 2.0 6
E94_040S2F_X -- 8.6 4.0 12
E94_080S2F_X -- 15.0 8.0 24
E94_100S2F_X -- 18.8 10.0 30
E94_120S2F_X -- 24.0 12.0 36
Single/Three-Phase Models
Type
(1)
Mains Voltage
(2)
1~ Mains
Current
3~ Mains
Current
Rated Output
Current
(5)
Peak Output
Current
(6)
E94_020Y2N_X
120 / 240V
(4)
1~ or 3~
(80 V -0%...264 V +0%)
5.0 3.0 2.0 6
E94_040Y2N_X 8.6 5.0 4.0 12
E94_080Y2N_X 15.0 8.7 8.0 24
E94_120Y2N_X 24.0 13.9 12.0 36
E94_180T2N_X
240V 3~
(180 V -0%...264 V +0%)
-- 19.6 18.0 54
E94_020T4N_X
400 / 480V
3~
(320 V -0%...528 V +0%)
-- 2.7 2.0 6
E94_040T4N_X -- 5.5 4.0 12
E94_050T4N_X -- 6.9 5.0 15
E94_060T4N_X -- 7.9 6.0 18
E94_090T4N_X -- 12.0 9.0 27
(1)
The first “_” equals either “P” for the Model 940 encoder based drive OR an “R” for the Model 941 resolver
based drive.
(2)
The second “_” equals either “E” for incremental encoder (must have E94P drive) OR an “R” for the standard
resolver (must have E94R drive).
(3)
Mains voltage for operation on 50/60 Hz AC supplies (48 Hz -0% … 62Hz +0%).
(4)
Connection of 120VAC (45 V … 132 V) to input power terminals L1 and N on these models doubles the
voltage on motor output terminals U-V-W for use with 230VAC motors.
(5)
Connection of 240VAC or 120VAC to input power terminals L1 and L2 on these models delivers an equal voltage
as maximum to motor output terminals U-V-W allowing operation with either 120VAC or 230VAC motors.
(6)
Drive rated at 8kHz Carrier Frequency. Derate Continuous current by 17% at 16kHz.
(7)
Peak RMS current allowed for up to 2 seconds. Peak current rated at 8kHz. Derate by 17% at 16kHz.
Applies to all models:
Acceleration Time Range (Zero to Max Speed) 0.1 … 5x10
6
RPM/sec
Deceleration Time Range (Max Speed to Zero) 0.1 … 5x10
6
RPM/sec
Speed Regulation (typical) ± 1 RPM
Input Impedance (AIN+ to COM and AIN+ to AIN-) 47 kΩ
Power Device Carrier Frequency (sinusoidal commutation) 8,16 kHz
Encoder Power Supply (max) +5 VDC @ 300 mA
Maximum Encoder Feedback Frequency 2.1 MHz (per channel)
Maximum Output Frequency (to motor) 400Hz
