P1 Pin Assignments (Input Power)
Standard Models Doubler Models
Pin Name Function Name Function
1 PE Protective Earth (Ground) PE Protective Earth (Ground)
2 L1 AC Power in N AC Power Neutral
(120V Doubler only)
3 L2 AC Power in L1 AC Power in
4 L3 AC Power in
(3~ models only) L2/N AC Power in (non-doubler operation)
P7 Pin Assignments (Output Power)
Pin Terminal Function
1 T1 Thermistor (PTC) Input
2 T2 Thermistor (PTC) Input
3 U Motor Power Out
4 V Motor Power Out
5 W Motor Power Out
6 PE Protective Earth (Chassis Ground)
5.1.2 P2 - Ethernet Communications Port
P2 is a RJ45 Standard Ethernet connector that is used to communicate with a host
computer via Ethernet TCP/IP.
P2 Pin Assignments (Communications)
Pin Name Function
1 + TX Transmit Port (+) Data Terminal
2 - TX Transmit Port (-) Data Terminal
3 + RX Receive Port (+) Data Terminal
4 N.C.
5 N.C.
6 - RX Receive Port (-) Data Terminal
7 N.C.
8 N.C.
Note
To communicate from the PC directly to the drive a crossover cable is
required. If using a Hub or Switch, a regular patch cable shall be used.
