Display Description
StAt
current drive status -
to view:
run - drive running
diS - drive disabled
F XX - drive fault. Where XX is the fault code (section 7.3.2)
Hx.xx Hardware revision (e.g. H2.00)
Fx.xx Firmware revision (e.g. F2.06)
bAUd
RS232/RS485(normal mode) baud rate -
to set
selects from 2400 to 115200 baudrates
Adr
Drive’s address -
to set
sets 0 - 31 drive’s address
FLtS
Stored fault’s history -
to view
scroll through stored faults F0XX to F7XX, where XX is the fault code (section
7.3.2)
Ht
Heatsink temperature -
to view
Shows heatsink temperature in ºC if greater than 40ºC. Otherwise shows “LO” (low).
EnC
Encoder activity -
to view
Shows primary encoder counts for encoder diagnostics activity
HALL
Displays motor’s hall sensor states -
to view
Shows motor hall states in form XXX , where X is 1 or 0 - sensor logic states.
buS
Displays drive DC bus voltage -
to view
Shows DC bus voltage value
Curr
Displays motor’s phase current (RMS)
Shows current value if drive is enabled, otherwise shows “DiS”
CAnb
CAN Baudrate
CAnA
CAN Address
CAno
CAN Operational Mode
CAnd
CAN Delay
CAnE
CAN Enable/disable
dHCP
Ehternet DHCP Configuration: 0=”dHCP” is disabled; 1=”dHCP is enabled.
IP 4
IP Adress Octet 4
IP 3
IP Adress Octet 3
IP 2
IP Adress Octet 2
IP 1
IP Adress Octet 1
