Basic units in the power range of 15 ... 90 kW
Terminal assignment - Standard I/O E82ZAFSC
7
Extensions for automation
7.4
7.4.2
L
7.4-5
EDS82EV903-1.0-11/2002
)
))
) Note!
l DIP switch and C0034 must be set for the same range,
otherwise the controller cannot interprete the analog signal to
X3/8 correctly.
l If a setpoint potentiometer is internally supplied through X3/9,
theDIPswitchmustbesetforavoltagerangeof0...5V.
Otherwise not the whole speed range can be provided.
Signal to X3/8
Switch position
C0034
1 2 3 4 5
0 ... +5 V OFF OFF ON OFF OFF 0
0 ... +10 V (Lenze setting) OFF OFF ON OFF ON 0
0 ... 20 mA OFF OFF ON ON OFF 0
4 ... 20 mA OFF OFF ON ON OFF 1
4 ... 20 mA Open-circuit monitoring OFF OFF ON ON OFF 3
-10V...+10V ON ON OFF OFF OFF 2
Configuration of the analog input
