Lenze E82EV113K4C - Page 261

Parameter setting with the E82ZBC keypad
Changing and saving par ameters
9
Parameter setting
9.3
9.3.4
L
9.3-5
EDS82EV903-1.0-11/2002
9.3.4 Changing and saving parameters
)
))
) Note!
l The user menu user is active after mains switching. Change to
the menu all to address all codes.
l In the different parameter sets only parameter values can be
changed with the keypad.
l Digital signals must be used to activate a parameter set for
operation (configuration with C0410)!
l In the function g the display shows the parameter set which
is just active during operation.
Step Keys Result Action
1. Connect keypad
g
xx.xx
Hz
Function g is activated. The first code in the user
menu will be displa yed (C0517/1, Lenze setti ng: C0050 =
output frequency).
2. If necessary change
t
 Change to function bar 2
3.
y
g
to the menu ”ALL”
wx
o
4.
yz
all Select menu ”ALL” (list of all codes)
5.
t
 Confirm selection and change to function bar 1
6. Select parameter
t
 Change to function bar 2
7.
p
set f or change
wx
m
8.
yz
1 ... 4 Select parameter set to be changed
9.
t
 Confirm selection and change to function bar 1
10. Inhibit controller
s dc
Only necessary if you want t o change C0002, C0148,
C0174 and/or C0469
11. Set parameters
wx f
12.
p
yz XXXX
Select code
13.
x k
001
For codes without subcodes: Jump automatically to i
14.
yz XXX
Select subcode
15.
x i
16.
yz XXXXX
Set parameters
17.
v STOre
Confirm entry if p is blinking
w
Confirm entry if p is not blinking; v is not active
18. Restart the ”loop” at 11. or 6. to set other parameters.
