Process controller
Switching off process controller functions
10
Function library
10.10
10.10.4
L
10.10-8
EDS82EV903-1.0-11/2002
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0184* Frequency
threshold
PCTRL1-I-OFF
0.0 0.0 {0.1 Hz} 25.0 • If the o utput fre quency < C0184, the
I component of the process controller
will be switched off
• 0.0 Hz = Function not active
^
10.10-5
Link the function with a digital input signal in C0410/18.
HIGH level at C0410/18 activates the function.
)
))
) Note!
In addition to the free configuration under C0410 you can also use
the fixed assignment under C0007 to combine the function with a
digital input.
Use C0184 to set the required frequency.
If the output frequency falls below the value in C0184, the integral-action
component will be switched off.
Activation
Activation via frequency
threshold
