Free connection of analog signals
Free configuration of analog outputs
10
Function library
10.12
10.12.2
L
10.12-7
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0419 Possible analog signals for C0419 ^
v
(cont.)
26 Output frequency normalised without s lip
(MCTRL1-NOUT-NORM)
10.12-4
(
)
27 Output frequency without slip (MCTRL1-NOUT)
6V/12mA/5.85kHz ≡ C0011
28 Act. process controller value (PCTRL1-ACT)
29 Process controller setpoint (PCTRL1-SET1)
6V/12mA/5.85kHz ≡ C0011
30 Process controller output without precontrol
(PCTRL1-OUT)
31 Ramp function generator input (NSET1-RFG1-IN)
32 Ramp function generator output (NSET1-NOUT)
33 (A ) PID controller output (PCTRL1-PID-OUT)
34 (A ) Process controller output (PCTRL1-NOUT)
35 Input signal at X3/8 (Standard-I/O) or X3/1U or
X3/1I (Application-I/O), evaluated with gain
(C0414/1 or C0027) and offset (C0413/1 or
C0026) (AIN1-OUT)
6V/12mA/5.85kHz ≡ Maximum value
analog input signal (5 V, 10 V, 20 mA, 10
kHz)
Condition: Gain of analog input or frequency
36 Input signal at frequency input X3/E1,
evaluated with gain (C0426) and offset (C0427)
(DFIN1-OUT)
C
o
n
d
i
t
i
o
n
:
G
a
i
n
o
f
a
n
a
l
o
g
i
n
p
u
t
o
r
f
r
e
q
u
e
n
c
y
input set to:
C0414/x, C0426 = 100 %
37 Motor potentiometer output⋅(MPOT1-OUT)
38 (A ) Input signal at X3/2U or X3/2I, evaluated with
gain (C0414/2) a nd of fset (C0413/2) (AIN2-OUT)
40 AIF input word 1 (AIF-IN.W1)
Setpoint to drive from communication
m
o
d
u
l
e
t
o
A
I
F
41 AIF input word 2 (AIF-IN.W2)
mo
d
u
l
e
t
o
A
I
F
10 V/20 mA/10 kHz ≡ 1000
50 CAN-IN1.W1 or FIF-IN.W1
Setpoints to drive from function module to
51 CAN-IN1.W2 or FIF-IN.W2
p
FIF
1
0
V
/
2
0
m
A
/
1
0
k
H
z
1
0
0
0
52 CAN-IN1.W3 or FIF-IN.W3
10
V
/
20 m
A
/
10
k
Hz ≡ 1000
53 CAN-IN1.W4 or FIF-IN.W4
60 CAN-IN2.W1
61 CAN-IN2.W2
62 CAN-IN2.W3
63 CAN-IN2.W4
255 Not assigned (FIXED-FREE)
C0108* Gain analog output
X3/62
(AOUT1-GAIN)
128 0 {1} 255 Standard I/O: C0108 a nd C0420 ar e the
same
Application I/O: C0108 and C0420/1 are the
same
^
10.12-4
C0109* Offset analog
output X3/62
(AOUT1-OFFSET)
0.00 -10.00 {0.01 V} 10.00 S t a ndard I/O: C0109 and C0422 are the
same
Application I/O: C0109 and C0422/1 are the
same
^
10.12-4
C0420* Gain analog output
X3/62
(AOUT1-GAIN)
Standard I/O
128 0 {1} 255 128 ≡ Gain 1
C0420 and C0108 are the same
^
10.12-4
C0422* Offset analog
output X3/62
(AOUT1-OFFSET)
Standard I/O
0.00 -10.00 {0.01 V} 10.00 C0422 and C0109 are the same ^
10.12-4
