10.13 Free connection of digital signals
10.13.1 Free configuration of digital input signals
l Internal digital signals can be freely assigned to external digital signal
sources. It is thus possible to achieve a freely configured control of the
controller
– Digital inputs X3/E1 ... X3/E6
– Digital process data input words
l A signal source can be assigned to several targets. Please ensure
reasonable assignments. Otherwise it is possible to activate functions
which cannot be operated together (e.g. a digital signal linked with quick
stop and DC braking at the same time).
)
))
) Note!
Use C0007 to configure some internal digital signals with the
digital inputs X3/E1 ... X3/E4 block by block. The corresponding
subcodes of C0410 will be adapted automatically.
Description
