Lenze E82EV113K4C

Free connection of digital signals
Free configuration of digital outputs
10
Function library
10.13
10.13.2
L
10.13-7
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0415 Possible digital signals for C0415 ^
v
(
t
)
0 Not assigned (FIXED-FREE)
10.13-6
(cont.)
1 Parameter set 2 or parameter set 4 is active
(DCTRL1-PAR-B0)
PAR-B1 PAR-B0
LOW LOW
LOW HIGH
HIGH LOW
HIGH HIGH
active
PAR1
PAR2
PAR3
PAR4
2 Pulse inhibit active (DCTRL1-IMP)
3 I
max
limit reached (MCTRL1-IMAX)
(C0014 = -5-: Torque setpoint re ached)
4 F requency setpoint reached
(DCTRL1-RFG1=NOUT)
5 Ramp function generator 1: Input = output
(NSET1-RFG1-I=O)
RFG1 = Ramp function generator main
setpoint
6 Value has fallen below frequency threshold Q
min
(f < C0017) (PCTRL1-QMIN)
LOW active
7 Output frequency = 0 (DCTRL1-NOUT=0)
8 Controller inhibit active (DCTRL1-CINH)
9...12 Reserved
13 Collective message
(DCTRL1-OH-PTC-LP1-FAN1-WARN):
Overtemperature warning (
ϑ
max
-5 °C)
(DCTRL1-OH-WARN)
or
Motor overtemperature warning
(DCTRL1-LP1-PTC-WARN)
or
set C0119 = 2 o r C0119 = 5
Motor phase failure warning (DCTRL1-LP1-WA RN)
or
set C0597 = 2
Fan failure warning
(only a ctive with 8200 motec)
Set C0608 = 0 fo r 8200 vector
14 DC-bus overvoltage (DCTRL1-OV)
15 CCW rotation (DCTRL1-CCW)
16 Ready for operation (DCTRL1-RDY)
17 Parameter set 3 or parameter set 4 is active
(DCTRL1-PAR-B1)
PAR-B1 PAR-B0
LOW LOW
LOW HIGH
HIGH LOW
HIGH HIGH
active
PAR1
PAR2
PAR3
PAR4
18 Value has fallen below TRIP or Q
min
or pulse
inhibit (IMP) is active (DCTRL1-TRIP-QMIN-IMP)
19
PTC warning (DCTRL1-PTC-WARN) set C0119 = 2 o r C0119 = 5
Status relay K
SR
Only with 8200 vector 15 ...90 kW, variant
”Safe standstill”:
HIGH = pulse inhibit active through ”Safe
standstill”
LOW = no pulse inhibit through ”Safe
standstill”
