Lenze E82EV113K4C

Type-specific accessories
Operation with rated power (mains voltage 1/N /PE AC 230 V)
17
Accessories (o ver view)
17.3
17.3.1
L
17.3-1
EDS82EV903-1.0-11/2002
17.3 Type-specific accessories
17.3.1 Operation with rated power (mains voltage 1/N/PE AC 230 V)
Mains voltag e 1/N/PE AC 230 V
8200 vector
g
E82EV251K2C E82EV371K2C E82EV551K2C E82EV751K2C E82EV152K2C E82EV222K2C
Accessories Order no.
E.l.c.b. EFA1C10A EFA 1C10A EFA1B10A EFA1B16A
EFA1B10A
2)
EFA1B20A
EFA1B16A
2)
EFA1B20A
Fuse EFSM-0100AWE EFSM-0100AWE EFSM-0100AWE EFSM-0160AWE
EFSM-0100AWE
2)
EFSM-0200AWE
EFSM-0160AWE
2)
EFSM-0200AWE
Fuse holder EFH10001
Mains choke ELN1-0900H005 ELN1-0500H009 ELN1-0250H018
3)
RFI filter LL
1)
E82ZZ37112B220 E82ZZ75112B220 -
RFI filter S D
1)
E82ZZ37112B200 E82ZZ75112B200 E82ZZ22212B200
RFI filter LD
1)
E82ZZ37112B210 E82ZZ75112B210 E82ZZ22212B210
Motor filter E82ZM22232B
Brake resistor ERBM470R020W ERBM200R100W ERBM082R150W ERBM052R200W
Swivel support E82ZJ001
DIN rail mounting E82ZJ002
EMC shield connection E82ZWEM1 E82ZWEM2 E82ZWEM2
PTC kit E82ZPE1 E82ZPE2 E82ZPE2
DC fuse without signalling device – EFSGR0100AYHN EFSGR0120AYHN EFSG R0250AYHN EFSGR0320AYHN
DC fuse with signalling device – EFS GR0100AYH K EFSGR0120AYH K EFSGR0250AYHK EFSGR0320AYHK
Plug connector (function module contact) E82ZJ011
1)
Only in combination with 8200 vector, types E82EVxxxKxC200
2)
For operation with mains choke
3)
Always use a mains choke
