Lenze E82EV113K4C

Type-specific accessories
Operation with rated power (mains voltage 3/PE AC 230 V)
17
Accessories (o ver view)
17.3
17.3.3
L
17.3-3
EDS82EV903-1.0-11/2002
17.3.3 Operation with rated power (mains voltage 3/PE AC 230 V)
Mains voltag e 3//PE AC 230 V
8200 vector
g
E82EV551K2C E82EV751K2C E82EV152K2C E82EV222K2C
Accessories Order no.
E.l.c.b. EFA3B06A EFA3B10A
EFA3B06A
2)
EFA3B16A
EFA3B10A
2)
EFA3B16A
EFA3B10A
2)
Fuse EFS M-0060AWE EFSM-0100AWE
EFSM-0060AWE
2)
EFSM-0160AWE
EFSM-0100AWE
2)
EFSM-0160AWE
EFSM-0100AWE
2)
Fuse holder EFH10001
Mains choke E82ZL75132B E82ZL 22232B
RFI filter S D
1)
E82ZZ75132B200 E82ZZ22232B200
RFI filter LD
1)
E82ZZ75132B210 E82ZZ22232B210
Motor filter E82ZM22232B
Brake resistor ERBM200R100W ERBM082R150W ERBM052R200W
Swivel support E82ZJ001
DIN rail mounting E82ZJ002
EMC shield connection E82ZWEM2
PTC kit E82ZPE2
DC fuse without signalling device EFSGR0080AYHN EFSGR0100AYHN EFSGR0160AYHN EFS GR0250AYH N
DC fuse with signalling device EFSG R0080AYHK EFSGR0100AYHK EFSGR0160AYHK EFSGR0250AYHK
Plug connector (function module contact) E82ZJ011
Mains voltag e 3//PE AC 230 V 8200 vector
g
E82EV302K2C E82EV402K2C E82EV552K2C E82EV752K2C
Accessories Order no.
E.l.c.b. EFA3B20A
EFA3B16A
2)
EFA3B25A
EFA3B20A
2)
EFA3B25A
2)
–
Fuse EFS M-0200AWE
EFSM-0160AWE
2)
EFSM-0250AXH
EFSM-0200AWE
2)
EFSM-0320AWH
EFSM-0250AXH
2)
EFSM-0320AWH
Fuse holder EFH10001 EFH10002
EFH10001
2)
EFH10002
Mains choke ELN3-0120H017 ELN3-0120H025 ELN3-0088H035
3)
RFI filter S D
1)
E82ZZ40232B200 E82ZZ75232B200
RFI filter LD
1)
E82ZZ40232B210 E82ZZ75232B210
Motor filter E82ZM75234B E82ZM11334B
Brake resistor ERBD047R01K2
Swivel support E82ZJ005 E82ZJ006
EMC shield connection E82ZWEM3
PTC kit E82ZPE3
DC fuse without signalling device EFSGR0320AYHN EFSGR0400AYHN –
DC fuse with signalling device EFSG R0320AYHK EFSGR0400AYHK –
Plug connector (function module contact) E82ZJ011
1)
Only in combination with 8200 vector, types E82EVxxxKxC200
2)
For operation with mains choke
3)
Always use a mains choke
