7 Commissioning
Setting for last bus node
EDK82ZAFIC−010 DE/EN/FR 4.064

H2_EinstellungLetzterTN−busteilnehmer
Setting for last bus node
DIP switch 1
ON
OFF
1
ON
234
E82ZAFI009
 Note!
ƒ DIP switch 1 must only be set to OFF for the last physical node.
ƒ Lenze setting: all switches OFF
Position Notes
OFF Standard device with function module is the last bus node
ON Standard device with function module is not the last bus node.
