Lenze E82ZAFIC010 - Commissioning steps

7 Commissioning
Commissioning steps
EDK82ZAFIC−010 DE/EN/FR 4.060

H2_Inbetriebnahmeschritte−inbetrieb
Commissioning steps
 Note!
Do not change the setting sequence.
Step−by−step commissioning of the function module with DRIVECOM device control is
described below.
Step Procedure Detailed
information
1. Configure the control system (master) for communication via the
function module.
62
2. Inhibit the standard device via terminal 28 (CINH).
l Apply LOW level to terminal 28.
l Later on, the standard device can be inhibited and enabled via the
bus system.
Documentation
for the standard
device
3. Set DIP switch S1:
l Setting for the last node = OFF
l Setting for all other nodes = ON
64
4. Define user data length via ...
l DIP switches S2 ... S4 or
l code C1515
63
5.
Connect the mains voltage and, if available, the separate voltage
supply for the function module.
l The standard device is ready for operation after approx. 1 second.
l The controller inhibit (CINH) is active.
65
Reaction
l The green LED "Status of connection to standard device" at the
front of the function module is lit (only visible with 8200 vector).
l Keypad: (if attached)
66
6.
It is now possible to communicate with the standard device, i.e. all
codes can be read and all writable codes can be adapted to the
application.
Documentation
for the standard
device
Reaction
The yellow LED on the function module is blinking when the
INTERBUS is active.
66
7. If PCP communication is used, carry out the PCP service "initiate".
l It is now possible to access the parameters of the standard device
with the PCP services "read" and "write".
