Electrical installation
Wiring of the feedback system
Encoder connection
5
126
EDKCSEX064 DE/EN/FR 6.0
Via the 9−pole Sub−D−plug X8, you can connect the following encoders:
ƒ Incremental encoder (TTL encoder)
with two 5 V complementary signals (RS−422) that are electrically
shifted by 90°.
with zero track that can be connected optionally.
ƒ Sin/cos encoder (singleturn or multiturn rotary transducer)
with supply voltage (5 ... 8 V).
with serial communication.
The initialisation time of the axis module is extended to approx. 2 s.
The controller supplies the encoder with voltage.
Use C0421 to set the supply voltage V
CC
(5 ... 8 V) to compensate, if required, the
voltage drop [DV] on the encoder cable:
DU ^ 2 @ L
L
[m] @ Rńm[Wńm] @ I
G
[A]
DV Voltage drop on the encoder cable [V]
L
L
Cable length [m]
R/m Ohmic resistance per meter of cable length [W/m]
I
G
Encoder current [A]
Stop!
Observe the permissible supply voltage of the encoder used. If the
values in C0421 are set too high, the encoder can be destroyed!
