Appendix
Code table
14

390
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0093 Drive ident
Device identification of the ECS
axis module
Read only
0 Defective power section
1 No power section recognised
4 ECSxS/P/M/A004C4
8 ECSxS/P/M/A008C4
16 ECSxS/P/M/A016C4
32 ECSxS/P/M/A032C4
48 ECSxS/P/M/A048C4
64 ECSxS/P/M/A064C4
65 ECSxS/P/M/A064C2
C0094 Password 0
Keypad password
Parameter access protection for
the keypad
0 {1} 9999
When the password is activated,
only the codes of the user menu
(C0517) can be accessed. Further
possible selections: see C0096
0 = no password
[C0095] Rotor pos adj 0
Activation of rotor position
adjustment for automatic
determination of the rotor
displacement angle.
C0058 displays the determined
rotor displacement angle (offset
angle).
 138
0 Inactive
1 Active
C0096 Extended password protection
for bus systems with activated
password (C0094)
All codes in the user menu can be
accessed.
1 AIF/CAN prot. 0 No access protection AIF access protection
2 AIF/CAN prot. 0 No access protection CAN access protection
0 No access protection Full access
1 Read protection Reading not possible
2 Write protection Writing not possible
3 Read/write protection Reading and writing not possible
C0097 DIS:Lt−Ident 0 Power stage identification
0 {1} 255
C0098 Set position 0
Home position of encoder
−2147483647 {1 inc} 2147483647
C0099 S/W version
Firmware version
Read only
0,0 {0,1} 25,5
C0105 QSP Tif 0.0
Deceleration time for quick stop
(QSP)
 324
 361
0.000 {0.001 s} 999.999 Relating to speed variation n
max
(C0011) ...0 rev./min.
