Lenze ECSxK001 series User Manual

Appendix
Code table
14

391
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0108 Gain for relative analog signals
(AOUT)
 347
1 FCODE(gain) 100.0 −199.99 {0.01 %} 199.99 FCODE_nC108_1_a
2 FCODE(gain) 100.0 FCODE_nC108_2_a
C0109 Offset for relative analog signals
(AOUT)
 347
1 FCODE(offset) 0.0 −199.99 {0.01 %} 199.99 FCODE_nC109_1_a
2 FCODE(offset) 0.0 FCODE_nC109_2_a
C0110 Service Code
Fine adjustment − mutual
inductance
50 {1 %} 200
C0111 Service Code
Fine adjustment − rotor
resistance
50.00 {1 %} 199.99
C0112 Service Code
Fine adjustment − rotor time
constant
50 {1 %} 200
C0113 Service Code
Fine adjustment − magnetising
current (I
sd
)
50 {1 %} 200
C0114 Polarity of the digital inputs
 129
1 DIGIN pol 0 HIGH level active X6/DI1 (DIGIN_bIn1_b)
2 DIGIN pol 0 HIGH level active X6/DI2 (DIGIN_bIn2_b)
3 DIGIN pol 0 HIGH level active X6/DI3 (DIGIN_bIn3_b)
4 DIGIN pol 0 HIGH level active X6/DI4 (DIGIN_bIn4_b)
0 HIGH level active
1 LOW level active
C0118 Polarity of the digital outputs
 345
 129
1 DIGOUT pol 0 HIGH level active X6/DO1 (DIGOUT_bOut1_b)
2 DIGOUT pol 0 HIGH level active X25 (DIGOUT_bRelais_b, brake
connection)
0 HIGH level active
1 LOW level active
C0120 OC6 limit 105
Threshold for I
2
x t monitoring
(motor)
 214
0 {1 %} 120 0 = I
2
x t monitoring is switched
off
I
2
x t > C0120 ð OC6−TRIP
C0121 OH7 limit 120
Threshold for motor temperature
monitoring
 206
45 {1 °C} 150 Motor temperature > C0121 ð
fault message OH7 (C0584)
C0122 OH4 limit 80
Threshold for heatsink
temperature monitoring
 208
45 {1 °C} 90 Heatsink temperature
> C0122 ð fault message OH4
(C0582)
C0123 OC7 limit 90
Threshold for I x t warning (axis
module)
 205
0 {1 %} 100 C0064 > C0123 ð fault message
OC7 (C0604)
