Process data transfer
Lenze device control
Process data signals for 82XX frequency inverters
7
l
50
EDSMF2133IB EN 5.0
Device control word AIF−CTRL for 82XX (C0135, index 5F78
hex
)
820X 821X / 822X / 824X
Bit Assignment Bit Assignment
0 / 1 JOG values 0 / 1 JOG values
Bit 1 0 Bit 1 0
0 0 C0046 active 0 0 C0046 active
0
1 JOG1 in C0037 active 0 1 JOG1 in C0037 active
1
0 JOG2 in C0038 active 1 0 JOG2 in C0038 active
1
1 JOG3 in C0039 active 1 1 JOG3 in C0039 active
2
CW/CCW rotation
2
CW/CCW rotation
0
1
CW rotation
CCW rotation
0
1
CW rotation
CCW rotation
3
Quick stop (QSP)
3
Quick stop (QSP)
0
1
QSP not active
QSP active
0
1
QSP not active
QSP active
4 ... 8 Reserved 4
Ramp function generator (RFG) stop
0
1
RFG stop not active
RFG stop active
5
Ramp function generator (RFG) zero
(Deceleration on the T
if
ramp C0013)
0
1
RFG zero not active
RFG zero active
6
UP function for motor potentiometer
0
1
UP not active
UP active
7
DOWN function for motor potentiometer
0
1
DOWN not active
DOWN active
8 Reserved
9
Controller inhibit (CINH))
9
Controller inhibit (CINH))
0
1
Not active
Active
0
1
Not active
Active
10 Reserved 10 Reserved
11 Reserved
11 TRIP reset
0 −> 1: Edge from 0 to 1
12
PAR1 (parameter set changeover)
12
PAR1 (parameter set changeover)
0 −> 1: Parameter set
1 −> 0: Parameter set
0 −> 1: Parameter set
1 −> 0: Parameter set
13 Reserved 13 Reserved
14
DC injection brake
14
DC injection brake
0
1
DC brake not active
DC brake active
0
1
DC brake not active
DC brake active
15 Reserved 15 Reserved
