3 Product description
Function
The communication module connects the Lenze inverter to the Ethernet POWERLINK
communication system.
Application as directed
The communication module ...
ƒ is a device intended for use in industrial power systems;
ƒ can only be used in POWERLINK networks;
ƒ can be used together with the following standard devices (nameplate data):
Device type Design
Version
Variant Explanation
HW SW
1)
82EVxxxxxBxxxXX
 Vx  1x
8200 vector
82CVxxxxxBxxxXX
 Vx  1x
8200 vector, cold plate
82DVxxxKxBxxxXX
 Vx  1x
8200 vector, thermally
separated
EPL 10200 E
 1x  1x
Drive PLC
33.93XX xE.
 2x  1x
Vxxx 9321 − 9332 vector
33.938X xE.
 1x  0x
9381 − 9383 vector
33.93XX xC.
 2x  1x
Vxxx 9321 − 9332, with cold
plate version
33.93XX EI / ET
 2x  1x
Vxxx 9300 Servo PLC
33.93XX CI / CT
 2x  1x
Vxxx 9300 Servo PLC, cold plate
ECSxSxxxx4xxxxXX
 1A  6.0
ECSxS "Speed & Torque"
ECSxPxxxx4xxxxXX
 1A  6.0
ECSxP "Posi & Shaft"
ECSxMxxxx4xxxxXX
 1A  6.0
ECSxM "Motion"
ECSxAxxxx4xxxxXX
 1A  2.3
ECSxA "Application"
ECSxExxxx4xxxxXX
 VA  3.0
ECSxE power supply
module
1) operating system software versions of the controllers
Any other use shall be deemed inappropriate!
