Appendix
Index table
8
43
EDSMF2191IB EN 2.0
I−1030:
EPL MAC address
Index
0x1030
EPL name
NMT_InterfaceGroup_0h_REC
Subcode Lenze Values Data type
1: InterfaceIndex_U16
0 U16
2: InterfaceDescription_VSTR EMF2191IB_1 VSTR
3: InterfaceType_U8 6 U8
4: InterfaceMtu_U32 1500 U32
5: InterfacePhysAddress_OSTR "00:0A:86:84:xx:xx" OSTR
6: InterfaceName_VSTR "IF1" VSTR
7: InterfaceOperStatus_U8 1 U8
Access: ro for subcodes 1, 2, 3, 4, 5
and 7
Access: rw for subcode 6
The object contains information on the Ethernet interface. The subcode 5 contains the
MAC address. When the communication module is produced, the MAC address is assigned
unequivocally worldwide and provides addressing on the lowest level.
I−1101:
EPL telegram counter
Index
0x1101
EPL name
DIA_NMTTelegrCount_REC
Subcode Lenze Values Data type
1: IsochrCyc_U32 U32
Access: ro
Subcode 1 of the object contains a counter for POWERLINK cycles. The counter is started
with each power−on of the node at 0. An overflow occurs at 4.294.967.295.
I−1400:
EPL address : RPDO
Index
0x1400
EPL name
PDO_RxCommParam_XXh_REC.NodeID_U8
Subcode Lenze Values Data type
100, 1 ... 240, 253, 254 U8
Access: rw
Subcode 1 of the object contains the node address (node ID) of the transmitting node for
the PDO channel (n+1).
Values > ’0’ describe the origin of a PRes telegram. The value ’0’ is reserved for "PReq"
(cannot be used in systems with a Lenze Servo Drive 9400 as managing node).
The value is only valid if the corresponding object 0x160x has a value > ’0’.
