Appendix
Index table
8

45
EDSMF2191IB EN 2.0
I−1601:
EPL number of RPDO
Index
0x1601
EPL name
PDO_RxMappParam_xxh_AU64.NumberOfEntries
Subcode Lenze Values Data type
000, 1 ... 32 U64
Access: rw
The object describes the number of valid mapping entries for the PDO channel (n+1).
The value ’0’ inhibits the PDO channel. The sum of all mapping entries enabled via the
objects 0x160x must not exceed the value ’64’.
I−1602:
EPL number of RPDO
Index
0x1602
EPL name
PDO_RxMappParam_xxh_AU64.NumberOfEntries
Subcode Lenze Values Data type
000, 1 ... 32 U64
Access: rw
The object describes the number of valid mapping entries for the PDO channel (n+1).
The value ’0’ inhibits the PDO channel. The sum of all mapping entries enabled via the
objects 0x160x must not exceed the value ’64’.
