Lenze EPL 10201-EI - Abmessungen bei Standard-Befestigung

Abmessungen bei Standard-Befestigung
O
EDK10200EV3 DE/EN/FR 5.0
NN
L
Abb. 1-2
M6
4Nm
35 lbin
a1
b1
f
b
a
c
d
b2
e
plc008
a [mm] a1 [mm] b [mm] b1 [mm] b2 [mm] c [mm] d [mm] e [mm] f [mm]
EPL-10200-EI 60 30 167 147 - 167 120 140 6.5 27.5 146
