Extension Board mounting (option)
EDK10200EV3 DE/EN/FR 5.0
L
QS
Note on Drive PLC with software version as of version 6 .1:
The Drive PLC detects automatically
z missing connections to the extension board.
z an extension board which is not compatible with the user program.
z a missing extension board.
Note on Drive PLC with software version earlier than version 6.1:
The Drive PLC does not detect automatically
z missing connections to the extension board.
z an extension board which is not compatible with the user program.
z a missing extension board.
Missing connections, incompatibility or missing extension boards can result in undefined actions
which can endanger the machine/system.
Therefore it is absolutely necessary to ensure that
z you always use two 26-pole plug connectors to connect the extension board with the Drive
PLC (see Mounting Instructions for the Extension Board, chapter “Mechanical installation”, plug
connectors ).
z the extension board type matches the user program.
iÉåòÉ éêçîáÇÉë ÑìåÅíáçå ÄäçÅâë ïÜáÅÜ Å~å ÄÉ äç~ÇÉÇ áåíç íÜÉ ìëÉê éêçÖê~ã
Ñçê íÜÉ aêáîÉ mi`KtáíÜíÜÉëÉ ÑìåÅíáçå ÄäçÅâë íÜÉ aêáîÉ mi` ÇÉíÉÅíëãáëëáåÖ
ÅçååÉÅíáçåë ~åÇ áåÅçãé~íáÄäÉ ÉñíÉåëáçå Äç~êÇë ~åÇ áåÇáÅ~íÉë Éêêçê
ãÉëë~ÖÉëK
qÜÉ ÑìåÅíáçå ÄäçÅâë Å~å ÄÉ Ççïåäç~ÇÉÇ Ñêçã íÜÉ iÉåòÉ ÜçãÉé~ÖÉW
ïïïKiÉåòÉKÇÉ EãÉåì “pÉêîáÅÉÒ
→ “açïåäç~ÇëÒ → “mi` mêçÇìâíÉÒFK
