z The software “Global Drive Control easy” is included on the CD-ROM “Drive PLC
Developer Studio”.
z The full version of “Global Drive Control” can be obtained from Lenze, with ordering
number ESP-GDC 2.
z A description of parameterization with the keypad can be found in the instructions
that are supplied with every keypad.
z The code table can be found in the online documentation of Drive PLC Developer
Studio (DDS).
Display of operating status
Two LEDs at the front of the instrument indicate the operating status of the Drive PLC:
^ÄÄK NJOP
LED
Operating status
green red
x blinking Fault: TRIP
blinks at 0.5 second intervals off PLC program not loaded
off off PLC program loaded
on off PLC program running
blinking every second off PLC program loaded but paused
x LED state has no significance
