Troubleshooting and fault elimination
EDK10200EV3 DE/EN/FR 5.0
RM
L
Display RemedyCauseError
Keypad PC
1)
ce2
63
Communication error to
CAN-IN2
CAN-IN2-object receives faulty data
or communication is interrupted
z Plug-in connection - bus module
Ù Check FIF
z Check transmitter
z Increase monitoring time under
C0357/2 if necessary
ce3
64
Communication error to
CAN-IN1 with event or time control
CAN-IN1-object receives faulty data
or communication is interrupted
z Plug-in connection - bus module
Ù Check FIF
z Check transmitter
z Increase monitoring time under
C0357/3 if necessary
ce4
65
BUS-OFF
(many communication errors oc-
curred)
The Drive PLC has received too
many incorrect telegrams via the
system bus and has been discon-
nected
z Check whether bus terminator
available
z Shield control of the cables
z Check PE connection
z Check bus load, if necessary,
reduce the baud rate
EEr
91
External fault (TRIP-Set) A digital signal assigned to TRIP set
has been activated
Check external encoder
H05
105
Internal fault Contact Lenze
per
74
Fault in program execution A fault was detected in the pro-
gram.
Send the Drive PLC with the data
set (on diskette) to Lenze.
pi
79
Initialisation error during transfer of
parameter set
z A fault was detected during the
transfer of the parameter set to
the Drive PLC.
z Parameter set does not match
Drive PLC
Correct the parameter set.
Pr0
75
Internal fault Contact Lenze
Pr1
72
Faulty transfer of PAR1 with key-
pad/PC
PAR1 is defective. Repeat data transfer or load Lenze
setting
Pr5
79
Internal fault Contact Lenze
1)
LECOM fault number
qáé>
Detailed information concerning system fault signals of the Drive PLC can be found in the
PDF manual ”Drive PLC” (chapter appendix: System fault signals)
