Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoSelectionLenze
Name
C047* Torque setpoint
I
max
limit value
Only display
- C005 = 4. 5
- Torque
setpoint
- C005 = 1. 2.
3. 6. 7
-I
max
limit
value (C022)
C049* Additional
setpoint
Only display
- Only when
C005 = 1. 2
C050* Output frequency Only display
C051* Actual PID
controller value
Only display
C052* Motor voltage Only display
C053* DC-bus voltage Only display
C054* Motor current Onlydisplay
C056* Unit load Only display
C061* Heat sink
temperature
Only display
C070 Gain
PID controller
1.00 0.00 {0.01} 300.00 0.0 = P-compone
nt inactive
C071 Integral action
time
PID controller
100 10ms 9999s 9999s = I-compo
nent inactive
C072 Differential
component
PID controller
0.0 0.0 {0.1} 5.0 0.0 = D-compone
nt inactive
C074 Influence PID
controller
0.0 0.0 {0.1 %} 100.0
C077* Gain
I
max
controller
0.25 0.00 {0.01} 1.00
C078* Integral action
time
I
max
controller
65 12 {1 ms} 9990
C079
Oscillation
damping
*depends on the
unit
822X/
824X
5 0 {1} 80
u
n
i
t
C088 Rated motor
current
* 0 {1 A} 480
0.0 ... 2.0
k rated output current
*depends on the
unit
C091 Motor cos j *
0.4 {0.1} 1.0
*depends on the
unit
