Lenze EVF8212-EV020

Configuration
821XKlimaBA0399 7-9
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoSelectionLenze
Name
C093*
Type Only display
821X 821X
822X 822X
824X 824X
C099* Software version 82 3x (Software 3x) Only display
C105 Deceleration time
QSP
5.00 0.00 {0.02s} 1300.00
C106 Holding time for
autom. DC
injection brake
0.02 0.00 {0.01s} 999.00
C108* Gain (C111) 128 0 {1} 255
C111
¤
Monitor signal -0-
-0- Field frequency
-1- Unit load
-2- Motor current
-3- DC-bus voltage
-4- Motor power
-5- Motor voltage
-6- Analog output 1/f
d
(1/C050)
-7- Field frequency of
f
dmin
(C010)... f
dmax
(C011)
-8- Actual PID controller value
Selection -9- ...
-25- corresponds
to the relay output
functions C008
andC117:
- LOW = 0 V
- HIGH = 10 V
-9- Ready for operation
-10- TRIP fault message
-11- Motor is running
-12- Motor is running / CW rotation
-13- Motor is running / CCW rotation
-14- Field frequency f
d
=0
-15- f
dset
reached
-16- Q
min
reached
-17- I
max
reached
-18- Overtemperature (
Ô
max
-10  )
-19- Setting of TRIP, Q
min
or Imp
822X/824X -20- PTC warning
-21- Apparent motor current (C054)< current
threshold (C156)
-22- Apparent motor current (C054)< current
threshold (C156)and
f
d
>Q
min
threshold
-23- Apparent motor current (C054)< threshold
(C156)and input of ramp function
generator = output of ramp function
generator
822X/824X -24- Warning motor phase failure
-25- f
d
(C050)< f
dmin
(C010)
