Lenze EVF8212-EV020

Configuration
7-10 821XKlimaBA0399
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoSelectionLenze
Name
C114
¤
Signal level
digital inputs
-0- E4 E3 E2 E1
-0-0000
-1-0001
-2-0010
-3-0011
-4-0100
-5-0101
-6-0110
-7-0111
-8-1000
-9-1001
-10- 1 0 1 0
-11- 1 0 1 1
-12- 1 1 0 0
-13- 1 1 0 1
-14- 1 1 1 0
-15- 1 1 1 1
0: Ex is not
inverted
1: Ex is inverted
C115
¤
Priority mask
digital inputs
-0- E4 E3 E2 E1
-0-0000
-1-0001
-2-0010
-3-0011
-4-0100
-5-0101
-6-0110
-7-0111
-8-1000
-9-1001
-10- 1 0 1 0
-11- 1 0 1 1
-12- 1 1 0 0
-13- 1 1 0 1
-14- 1 1 1 0
-15- 1 1 1 1
0: Function Ex
depends on C001
1: Function Ex is
independent of
C001
- Ctrl. inhibit and
TRIP reset
always have
first priority.
- Wit h - 0- also
TRIP set and
QSP have
priority.
C119
¤
Function PTC
822X/824X
-0- -0- PTC input not active
-1- PTC input active, TRIP and pulse inhibit will
be set
-2- PTC input active, warning
C120
I
2
k t switch off
822X/824X 0 0 {1 %} 100
C125
¤ *
LECOM baud rate -0- -0- 9600 baud
-1- 4800 baud
-2- 2400 baud
-3- 1200 baud
-4- 19200 baud
Only for LECOM
applications
