Wiring the standard device 7
61
EDK94AMH24 DE/EN/FR/ES/IT 1.0
System bus CAN on board
Terminal X1 Labelling Description
Pin 2 CAN-LOW
Pin 3 CAN-GND
Pin 7 CAN-HIGH
9400SSP000X1
(Housing) CAN-Shield
Note!
The ”StateLine” design does not provide this connection.
24 V supply
Terminal X2 Labelling Description
GE GND external supply
24E 24 V external supply via a safely separated power supply unit
(SELV/PELV)
9400SSP000X2
SB State bus in/out (reference GE)
Terminal data
Conductor cross-section Tightening torque
[mm
2
] [AWG] [Nm] [lb-in]
Flexible
0.2 ... 2.5
24 ... 12 Spring terminal
With wire end
ferrule
