Operating instructions i550 motec frequency inverter | 27
© 03/2022 · EN · www.Lenze.com
Index Name Possible settings/value ranges Selection no. Information
0x2631:008 Run forward Not connected [0]
Assignment of a trigger to the “Run forward (CW)” function.
Trigger = TRUE: Let motor rotate forward.
Trigger = FALSE: Stop motor.
0x2631:009 Run reverse Not connected [0]
Assignment of a trigger to the “Run reverse (CCW)” function.
Trigger = TRUE: Let motor rotate backward.
Trigger = FALSE: Stop motor.
0x2631:013
Reverse rotating
direction
Not connected [0]
Assignment of a trigger to the “Reverse rotating direction” function.
Trigger = TRUE: The setpoint specied is inverted (i.e. the sign is inverted).
Trigger = FALSE: No action/deactivate function again.
0x2631:018 Activate preset (bit 0) Not connected [0]
Assignment of a trigger to the “Activate preset (bit 0)” function.
Bit with the valency 2
0
for the bit-coded selection and activation of a parameterized setpoint (preset value).
Trigger = FALSE: Bit = “0”.
Trigger = TRUE: Bit = “1”.
0x2631:019 Activate preset (bit 1) Not connected [0]
Assignment of a trigger to the “Activate preset (bit 1)” function.
Bit with the valency 2
1
for the bit-coded selection and activation of a parameterized setpoint (preset value).
Trigger = FALSE: Bit = “0”.
Trigger = TRUE: Bit = “1”.
0x2631:020 Activate preset (bit 2) Not connected [0]
Assignment of a trigger to the “Activate preset (bit 2)” function.
Bit with the valency 2
2
for the bit-coded selection and activation of a parameterized setpoint (preset value).
Trigger = FALSE: Bit = “0”.
Trigger = TRUE: Bit = “1”.
0x2634:002 Digital output 1 Operation enabled [52]
Assignment of a trigger to digital output 1.
Trigger = FALSE: X3.1/DO1 set to LOW level.
Trigger = TRUE: X3.1/DO1 set to HIGH level.
0x2911:001
Setpoint frequency
presets: Preset value 1
0.0 ... 20.0 ... 599.0Hz
Parameterizable frequency setpoints
0x2911:002
Setpoint frequency
presets: Preset value 2
0.0 ... 40.0 ... 599.0Hz
0x2911:003
Setpoint frequency
presets: Preset value 3
0.0 ... 50.0 ... 599.0Hz
0x2911:004
Setpoint frequency
presets: Preset value 4
0.0 ... 0.0 ... 599.0Hz
* Default setting dependent on the model
